Dahua 16 Channel NVR

Dahua DHI-NVR2116-4KS3. 16 channel Dahua IP NVR. Smart H.265+/Smart H.264+. 144/72Mbps input/output. Simultaneous HDMI (4K) and VGA (1080P) outputs. Compatible with smart cameras. 4-channel SMD Plus. 1 SATA HDD capacity. 1 RJ45 Fast Ethernet. 2 USB 2.0. 12V DC 16-channel dahua ip nvr.

16 IP channels
Video compression: Smart H.265+, Smart H.264+, H.265, H.264, and MJPEG.
Simultaneous HDMI (4K) and VGA (1080P) video outputs
Output division: 1, 4, 8, 8, 9, 9, 16
1 input / 1 output RCA audio
Audio compression: G.711a, G.711u, PCM, G726
Recording resolution: 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
Bandwidth with AI disabled: 144 Mbps input, 144 Mbps for recording, 72 Mbps output
AI enabled bandwidth: 72 Mbps input, 72 Mbps recording, 36 Mbps output
Decoding capacity with AI disabled:
1 channel at 12MP (30 fps)
1 channel at 8MP (30 fps)
2 channels at 5MP (30 fps)
3 channels at 4MP (30 fps)
6 channels 1080P (30 fps)
AI-enabled decoding capability:
1 channel at 8MP (30 ips)
1 channel at 5MP (30 fps)
2 channels at 4MP (30 fps)
4 channels 1080P (30 fps)
General, motion detection, intelligence, alarm, alarm recording modes
Alarm by videosensor, external camera alarm, PIR alarm
Artificial Intelligence from intelligent cameras:
Perimeter protection: 4 channels
SMD Plus: 4 channels
Artificial Intelligence in the recorder:
SMD Plus: 4 channels
Playback of up to 16 channels
Internal capacity for 1 SATA HDD up to 20TB (sold separately)
RJ45 Fast Ethernet network port (10/100Mbps)
Network Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filtering, DDNS, IP Search (supports IP cameras, DVR, NVS, etc.), P2P, Auto Logging
ONVIF 22.12 (T/S/G), CGI and SDK support
Compatible with Chrome, IE, Safari, Edge, Firefox web browsers
Compatible with Android and iOS devices
Server Access local network and Internet
Ability to limit user access to cameras in local and/or remote mode
Can be remotely controlled via Joystick keyboard connected by TCP/IP
Sending of eMails with photo attached in alarm
Sending to FTP programmed or in alarm
Possibility to send alarm, and be connected to video surveillance receiver software
Possibility of fixed or dynamic IP through Dyndns, NoIP, DDNS Evolution, etc. service.
Communication ports: 2 USB 2.0 ports
Power supply: 12V DC, 1.5A
Power consumption: ≤10W (excluding disks)
Storage temperature from -20°C ~ +60°C
Operating temperature from -10°C ~ +55°C
Relative humidity 10%~93% (non-condensing)
Dimensions: 204.6 (W) x 45.6 (H) x 206.4 mm (W x H) x 206.4 mm (H x D)
Net weight: 450 g
Gross weight: 1.05 kg
Tabletop installation
